Volvo ECR18E
Compact excavators
- Extended warranty
- Flexible financing
- Tailored service contracts
The Volvo ECR18E combines big performance with an ultra-compact design, allowing it to squeeze into the tightest of spaces. This short swing radius machine is engineered to work safely and efficiently close to obstacles without risk of collision.
As a versatile performer in the 1.8-ton class, its ability to access restricted areas opens up new possibilities for landscaping, utility, and construction jobs. Despite its small size, it delivers the powerful and reliable performance you expect from a Volvo.
Technical specifications
Here are the key specifications for ECR18E. Want more details? Download the brochure or contact us.
- Max operating weight 1 700 kg
- Engine Volvo D0.9A
- Bucket capacity 0.01 - 0.05 m³
- Gross power 12 kW
- Net power 11.80 kW
- Net power at engine speed 2 300 rpm
- Operating weight, canopy version 1 700 kg
- Travel speed, low / high 1.8 / 3.5 km/h
- Slewing speed 9.50 rpm
- Breakout force 12.90 kN
- Tear out force (arm breakout force) 8 kN
- Overall length 3 431 m
- Overall width 995 mm
- Main hydraulic pump max. flow 34 l/min
Benefits & Features
Here are the key benefits and features of the ECR18E. Want to know more? Download the brochure or get in touch with us.
Ultra-Short Tail Design
Work with total confidence in confined spaces. With the shortest tail radius in the Volvo range, the rear of the machine stays within the tracks when turning, preventing collisions and making it ideal for the tightest job sites.
Variable Undercarriage
Access almost any work area. The undercarriage can be hydraulically retracted for passing through narrow gates and doorways, and then extended for superior stability, giving you unmatched versatility and access.
