Volvo EC480E
Large crawler excavators
- Extended warranty
- Flexible financing
- Tailored service contracts
The Volvo EC480E crawler excavator is a production powerhouse designed to maximize output while lowering fuel consumption. Equipped with advanced technology such as Volvo’s unique ECO mode and a new electro-hydraulic control system, it delivers significant improvements in fuel efficiency without compromising performance.
Engineered for reliability and strength, the EC480E combines a high-performance Volvo engine with a reinforced undercarriage and durable components to handle the toughest applications. Its precise hydraulics and intelligent control ensure faster cycle times and smoother operation, helping contractors increase productivity on every site.
With Volvo’s renowned operator comfort, spacious cab, and simplified maintenance access, the EC480E is the ultimate solution for contractors seeking efficiency, durability, and profitability in large-scale excavation and quarrying.
Technical specifications
Here are the key specifications for EC480E. Want more details? Download the brochure or contact us.
- Operating weight 45 500 - 53 300 kg
- Gross power 278 kW
- Lifting capacity, along undercarriage 17 590 kg
- Lifting capacity, along undercarriage at reach / height 6 / 1.5 m
- Max digging reach 12 146 mm
- Max digging depth 7 828 mm
- Breakout force, SAE J1179 (Normal) 230 kN
- Breakout force, SAE J1179 (Boost) 251 kN
- Tear out force, SAE J1179 (Normal) 196 kN
- Tear out force, SAE J1179 (Boost) 215 kN
- Tail swing radius 3 800 m
- Bucket capacity 1.55 - 3.30 m³
- Overall width 3 640 mm
Benefits & Features
Here are the key benefits and features of the EC480E. Want to know more? Download the brochure or get in touch with us.
Powerful and Reliable Volvo Engine
The robust Volvo D13 engine is at the heart of the machine, delivering high torque at low rpm. This provides the power needed for heavy-duty tasks while ensuring the reliability and long service life you expect from Volvo.
Advanced Hydraulic System
Experience fast cycle times and smooth control with the advanced hydraulic system. It is optimized to work in harmony with the engine, providing high hydraulic flow for responsive and highly productive combined operations.
Reinforced and Durable Undercarriage
Engineered for maximum uptime in the toughest jobs like quarrying. The reinforced undercarriage with durable components is designed to withstand high-impact forces, delivering the ultimate in durability and reliability.
