Dynapac CA1300D
Small Compacting
- Extended warranty
- Flexible financing
- Tailored service contracts
The Dynapac CA1300D is the most compact soil compactor in the range, making it the ideal choice for compaction in the most restricted areas. It is specially designed for utility work, trench compaction, and small-scale repair or landscaping projects.
This machine combines a very small footprint with the power needed to achieve excellent results on granular soils. Its agility and ease of operation allow it to work safely and efficiently close to obstacles, delivering Dynapac’s renowned performance in a minimal size.
Technical specifications
Here are the key specifications for CA1300D. Want more details? Download the brochure or contact us.
- Operating mass (incl. ROPS) 4 750 kg
- Operating mass (incl. Cab) 5 000 kg
- Max. operating mass 5 450 kg
- Tyre size (12 ply) 12.5 - 20
- Max. theoretical gradeability 55 %
- Speed range 0 6 km/h
- Manufacturer / Model Kubota V 3307 CR-TE4 (Stage IIIB/T4f)
- Type Water cooled turbo Diesel
- Rated power, SAE J1995 55 kW (75 hp) @ 2200 rpm
- Fuel tank capacity 117 l
- Driving Axial piston pump with variable displacement. Axial piston motor with constant displacement. Radial piston motor with constant displacement.
- Vibration Gear pump/ motor with constant displacement.
- Steering Gear pump with constant displacem.
- Service brake Hydrostatic in forward and reverse lever.
- Parking Failsafe multidisc brake in rear axle and front drum motor.
- Compaction width 1 370 mm
Benefits & Features
Here are the key benefits and features of the CA1300D. Want to know more? Download the brochure or get in touch with us.
Ideal for Confined Areas
As the most compact roller in the family, the CA1300D is designed to operate efficiently in tight spaces like trenches and around foundations, bringing powerful compaction to any job.
Operator Safety and Visibility
The operator’s platform is designed for a clear, unobstructed view of the work area and drum. This focus on visibility enhances safety and allows for precise compaction, even when working close to obstacles.
